Aico 230V 3000 Series Optical And Heat Multi-Sensor Fire Alarm - Ei3024

The Aico Ei3024 Multi-Sensor Fire Alarm contains both Optical and Heat sensors to provide total fire coverage. Intelligent software allows it to detect all fire types (TF1 to TF6 & TF8) with an increased resistance to false alarms. It’s ability to respond quickly to both fast flaming and smouldering fires, simplifies alarm choice for the designated rooms/areas.  In addition, the chamber design, integrated insect screen and unique dust compensation algorithm reduce the risk of false alarms. The Ei3024 runs on 230V AC mains power. In the event of mains failure, the 10 Year+ built in tamper-proof rechargeable lithium cells will provide back-up supply and continuous operation.

The Multi-Sensor Fire Alarm contains AudioLINK technology, which allows you to extract real time data from the alarm using its sounder directly to a smartphone or tablet via an App. A simple to read report is generated displaying details such as activation dates, sensor status and alarm life, that can be emailed to help form part of property records.

The Ei3024 Multi-Sensor Fire Alarm is SmartLINK compatible, Simply plug in an Ei3000MRF module for wireless interconnection, data extraction and real-time notifications of alarm activation's and events via the SmartLINK Gateway and Portal.

The alarm has a unique self-monitoring dust compensation mechanism incorporated into its software, which will allow the alarm to tolerate up to twice as much more dust contamination than a conventional optical alarm. The optical sensor chamber continually self-monitors minute changes in dust levels. If the dust accumulates to a certain level, the alarm automatically recalibrates the alarm trigger point.

The Ei3024 Multi-Sensor Fire Alarm is fully compatible with all other Aico alarms and accessories whether a system needs upgrading or an existing system needs expanding; and works with either hard-wired, RadioLINK or hybrid interconnecting systems.

Technical Specification:



  • Sensor Types: Optical & Thermistor
  • Supply Voltage: 230V AC, 50Hz
  • Power Consumption: 0.25W (standby)
  • Battery Back-up: Rechargeable lithium cells
  • Sound Level: 85dB(A) at 3m
  • Button Test: Checks sensors, electronics and sounder
  • Silence Function: Silences alarm for 10 minutes
  • Silence Function: Silences fault beeps for 12 hours
  • AudioLINK: Enabled
  • SmartLINK: Compatible via the Ei3000MRF Module
  • Indicator LED’S: Green – power. Red – alarm/ silence mode/ memory. Yellow – fault event
  • Memory: Records last alarm event
  • Fixing: easi-fit base (supplied)
  • Operating Temperature: -10°C to 40°C
  • Humidity Range: 15% to 95% relative humidity
  • Plastic Material: UL 94 V0 flame retardant
  • Dimensions – Product: 150mm x 66mm
  • Dimensions – Boxed: 180mm x 155mm x 70mm
  • Weight: 346g (product only), 412g (boxed)
  • Guarantee: 5 years
